16Amp 11KW E V Wallbox EV Charging Stations Near Me Electric Car Charger Point
| Item | 11KW AC EV Charger Station | |||||
| Product Model | MIDA-EVST-11KW | |||||
| Rated Current | 16Amp | |||||
| Operation Voltage | AC 400V Three Phase | |||||
| Rated frequency | 50/60Hz | |||||
| Leakage Protection | Type B RCD / RCCB 30mA | |||||
| Shell Material | Aluminum Alloy | |||||
| Status Indication | LED Status Indicator | |||||
| Function | RFID Card | |||||
| Atmospheric Pressure | 80KPA ~ 110KPA | |||||
| Relative Humidity | 5%~95% | |||||
| Operating Temperature | -30°C~+60°C | |||||
| Storage Temperature | -40°C~+70°C | |||||
| Protection Degree | IP55 | |||||
| Dimensions | 350mm (L) X 215mm (W) X 110mm (H) | |||||
| Weight | 7.0 KG | |||||
| Standard | IEC 61851-1:2010 EN 61851-1:2011 IEC 61851-22:2002 EN 61851-22:2002 |
|||||
| Certification | TUV,CE Approved | |||||
| Protection | 1.Over and under frequency protection2. Over Current Protection
3.Leakage Current Protection (restart recover） 4. Over Temperature Protection 5.Overload protection (self-checking recover) 6. Ground Protection and Short circuit protection 7.Over voltage and under-voltage protection 8. Lighting Protection |
|||||
