DC Bidirectional Module DC-DC Charging Module

Short Description:

Dimensions:85mm(H)×226mm(W)×376mm(D)

Weight:≤9.5kg

Efficiency(full load):>98.5%

Cooling Mode: Forced air cooling

Communication Bus Protocol: CAN bus

No. of Parallel Modules: ≤60 pcs

Indicator:Green: normal operation Yellow: protection alarm Red: fault


Product Detail

Product Tags

DCDC Bidirectional Module DC Charging Module

MD95050Bis a high-frequency isolated bi-directional Dc-Dc module with core advantageousperformance such as ultra-wide voltage range, ultra-high full-load operating temperature and ultra-highefficiency.The strong protection and high power density are also the main features of the moduleMD95050B can be widely used in interaction between Dc bus side and battery side, such as energy storage,PV, ESS and charging, battery cascade utilization, data center and other multi-energy complementaryscenarios.

Charging: in the range of 400-950v, the output power of the module is limited to 20kW; in the range of 200v.
400V,the current of the module is limited to 50ADischarge: in the range of 400-950v, the output power of the module is limited to 20kw; in the range of 200v.
400V,the current of the module is limited to 50A.Under voltage protection for module will start if the voltage is below 200v. The charge-discharge curve on thebattery side is completely symmetrical.

The voltage-current relationship on the bus sideThe voltage-current relationship on the bus side is shown in Figure 1-2.Charging: in the range of 500-950v,the input power of the module is limited to 20kw; in the range of 200v-500V, the current of the module is limited to 40A.
Discharge: in the range of 500-950v, the output power of the module is limited to 20kw; in the range of 200v.
500V,the current of the module is limited to 40A.
Under voltage protection for module will start if the voltage is below 200v, The charge-discharge curve on the busside is completely symmetrical.
