Type 1 Portable ev charger with CEE plug 10A / 16A / 20A/ 24A / 32A Electrical Car Charger level 2

Short Description:

Rated current: 10A / 16A / 20A/ 24A / 32A ( Optional )

Operating voltage: 110V~250V AC

Delay Charging: 1-12Hour

Insulation resisitance:>1000MΩ
Therminal temperature rise:<50K
Withstand voltage:2000V
Working temperature: -30°C ~+50°C
Contact impedance: 0.5m Max


Product Detail

Product Tags

Portable EV chargers are also very easy to use. Just plug it into your car's charging port and it will automatically start charging your battery. It's that simple! This means you don't have to spend time looking for a charging station or worry about complicated instructions or procedures.

32A CEE EV Charger Type 2

 But perhaps the most important benefit of a portable EV charger is its ability to charge your car quickly and efficiently. Thanks to its advanced technology and high power output, it charges your battery faster than other charging methods, which saves you valuable time and gets you back on the road sooner.



EV Charging Box IEC 62752  ,  IEC 61851 Standard
Power Plug Type 1 /Type 2
Rate Current 6A ,8A ,10A ,13A(3Pin UK plug)                     3.2KW
Rate Current 6A ,8A ,10A ,13A,16A (EU Schuko plug)        3.6KW
Rate Current 10A ,16A ,20A ,24A,32A (Blue 3pin CEE plug)  7.2KW
Input Voltage 220V/50Hz
Waterproof Rating IP67
Operating Temperature -25°C ~ +55°C
Storage Temperature -40°C ~ +80°C
LCD Display Temperature, Charging Time, Actual Current, Actual Voltage, Actual Charging PowerDelay Time
New Function Delayed Charging (1~12)+ Current Switching
Control Box Dimensions 220mm (L) X 100mm (W) X 56mm (H)
Cable Length 5 Meter
Certification TUV,CE ,UKCA,FCC Certificate
Protection 1.Leakage Current Protection                2. Over Current Protection 3.Over Voltage Protection                      4. Under Voltage Protection5.Over Temperature Protection              6. Low Temperature Protection7.Short Circuit Protection                        8. Surge Protection

9.Overload Protection (self-checking recover)
